Product Description ： 1、IPD miniaturization design ，support GPS/BD2/GLONASS band； 2、Miniaturization, high performance, low cost, high reliability， dimension：5.6mmX5.9mmX1.4mm； 3、LNA, SAW filters, chip capacitors, inductors
| Antenna |
Center Frequency |
1550～1610MHz |
Gain |
28±2dB | |
Noise Figure |
1.5dB max | |
| Ex-band Attenuation | 40dB | |
| Voltage | DC 3.0~5.0V | |
| Current | 10～13 mA | |
| 1dB compression point output | -8 dBm | |
| Environmental | Operating Temperature | -40℃ to +85℃ |
| Relative Humidity | Up to 95℃ | |
| Environmentally Friendly | ROHS Compliant |
| Pin# | Name | Description | Pin# | Name | Description |
| 1 | GND | Ground | 6 | GND | Ground |
| 2 | RFin | RF input | 7 | GND | Ground |
| 3 | GND | Ground | 8 | GND | Ground |
| 4 | 3.3V | supply voltage | 9 | RFout | RF output |
| 5 | GND | Ground | 10 | GND | Ground |
